Archive for the ‘3D CAD DESIGNS’ Category
PNEUMATIC DISTRIBUTOR FINS ACTUATION
Posted: September 21, 2014 in 3D CAD DESIGNS, PNEUMATIC DISTRIBUTOR TMHK PROJECT
PNEUMATIC DISTRIBUTOR TMHK PROJECT
Posted: December 8, 2013 in 3D CAD DESIGNS, PNEUMATIC DISTRIBUTOR TMHK PROJECT
WORKING PRESSURE UP TO 12 BAR DUE TO THE HIGH MACHINING PRECISION CLASS. TOTAL LENGHT:110mm TOTAL HEIGHT:20mm TOTAL WIDTH OF THE MAIN CASE :26mm TOTAL WIDTH WITH THE PENUMATIC ADAPTORS BOLTED IN THE MAIN CASE:46.5mm
3D DESIGN PERSONAL CONCEPT COPYRIGHT
The platform have 6 points of freedom. The design combines multiple designs found on internet. The kinematics have been tested in SolidWorks and can be adapted.
The platform have 6 points of freedom. The design combines multiple designs found on internet. The kinematics have been tested in SolidWorks and can be adapted.
Adrian Hainarosie C.A.D. Mechanical Designer & C.A.M. Programming C.N.C. Manufacturing.
