TMHK PERSONAL CONCEPT – INTAKE SIMULATION
Posted: November 26, 2013 in FLOW SIMULATIONS WATER AND AIR, TOMAHAWK Personal Concept
The design with the 5 scoops burried into the fuselage increases the flow into the engines intake. The NACA profiles are carefully determined for the intake to keep the lowest possible drag force.
The nose shape will improve stability to compensate the centrifugal force caused by the engine.
I added 5 scoop intakes for a better flow. The intake profiles are NACA.
TMHK OLD DESIGN ISOMETRIC BACK VIEW
Posted: November 26, 2013 in FLOW SIMULATIONS WATER AND AIR, TOMAHAWK Personal Concept
This is a simulation of pressure points according to different speeds.
Adrian Hainarosie C.A.D. Mechanical Designer & C.A.M. Programming C.N.C. Manufacturing.
